Rich Solar WindyNation 4/0 Gauge Pure Copper Battery Cables With 3/8 Lugs

Durable Heat?Shrink Wiring Tubing for Vehicles and DC Systems

Flexible PVC heat?shrink tubing designed for replacing or upgrading wiring in cars, motorcycles, RVs, campers and trailers, and for use with grounding, golf carts, car audio, solar systems and DC power inverters. It protects connections, handles wide temperature swings, and fits a variety of DC applications.

Benefits

• Makes installations faster and neater by shrinking to form a snug, protective cover over joints and terminals.
• Reduces maintenance and rework by protecting wires from moisture, abrasion and vibration.
• Improves safety and reliability for vehicle and off?grid electrical systems with high dielectric strength and UL approval.
• Works across many applications — one product covers audio installs, grounding, solar and inverter hookups so you don’t need multiple part types.
• Performs in extreme temperatures so connections stay secure in hot summers and cold winters.

Features

• Polyvinyl chloride (PVC) insulation provides flexible, durable protection.
• Approximately 3:1 shrink ratio for tight, conforming coverage.
• Rated for MTW at 194°F and listed to UL & CSA at 221°F.
• Voltage rating up to 600 volts for many DC wiring needs.
• VW?1 flame rating and moisture resistant for added safety.
• RoHS compliant and UL approved for regulatory compliance and quality assurance.

Specifications

• Shrink ratio: Approximately 3 to 1 at +194°F
• Operational temperature range: -67°F to +275°F
• Dielectric strength: 500 V/mil (197 kV/cm)
• Volume resistivity: 1×10^14 ohm·cm
• Tensile strength: 1500 psi (141 kg/cm²)
• Insulation material: Polyvinyl chloride (PVC)
• Voltage rating: Up to 600 volts
• Approvals and ratings: VW?1, moisture resistant, RoHS compliant, UL approved; MTW 194°F — UL & CSA 221°F
