Rich Solar Bravo 30 MPPT Solar Charge Controller 30A 12V 24V

Compact MPPT Solar Charge Controller — Reliable, Efficient, Easy to Monitor

Overview

A compact MPPT solar charge controller that maximizes energy harvest, protects your battery and system, and gives you simple, real?time monitoring via Bluetooth. Designed for 12V/24V setups, it performs well in low light and partial shading while supporting multiple battery chemistries.

Benefits

• Get more usable solar power from the same panels thanks to high MPPT and conversion efficiency.
• Extend battery life with multi?stage charging and customizable charge settings for different chemistries.
• Keep the system running reliably in dim or partially shaded conditions, reducing downtime.
• Monitor performance and adjust settings quickly from your phone via built?in Bluetooth and the app.
• Install confidently with automatic 12V/24V detection and multiple safety protections to prevent common faults.

Features

• Advanced MPPT algorithm with up to 99.5% tracking efficiency to capture more solar energy.
• High conversion efficiency (up to 98%) for effective power transfer from panels to battery.
• Stable operation under low?light and partial shading conditions.
• Auto?detects 12V or 24V systems for easy setup and seamless integration.
• Supports multiple battery types: GEL, AGM, WET, CRYSTAL, CALCIUM, LiFePO4, LTO, LCO, and Custom profiles.
• Multi?stage charging algorithm with adjustable parameters to optimize charging and prolong battery life.
• Comprehensive protection suite: over?voltage, reverse polarity, short?circuit, and over?temperature protection.
• Weather?resistant construction with IP43-rated PCBA and IP22-rated connectors for outdoor use.
• LCD + LED display for real?time solar input and battery status with configurable settings.
• Built?in Bluetooth for app monitoring (Rich Solar App) and optional remote meter and temperature sensor support.
• Certifications: ETL, FCC, CE, RoHS.

Specifications

• Maximum Solar Input Current: 30A
• Maximum Charging Current: 30A
• Recommended Solar Power: 500W (12V) / 1000W (24V)
• Nominal System Voltage: 12V / 24V (auto?detect)
• Solar Input Voltage Range: 8V – 100V
• MPPT Voltage Range: 15V – 72V
• Maximum Conversion Efficiency: 98%
• Maximum MPPT Tracking Efficiency: 99.5%
• Battery Compatibility: GEL, AGM, WET, CRYSTAL, CALCIUM, LiFePO4, LTO, LCO, Custom
• Connectivity: Built?in Bluetooth; optional remote meter and temperature sensor
• Protection Rating: IP43 (PCBA), IP22 (connections)
• Certifications: ETL, FCC, CE, RoHS
• Net Weight: 1.8 lb
• Dimensions (L x W x H): 7.0 × 5.5 × 2.9 in
